Leading ANSI/ASME B16.9 Butt weld Long Stub End Manufacturers and Authoritative SS Long Stub End Supplier in India and Overseas.
As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld long stub end, we are providing high-quality long neck stub end at best price in India.
We keep the largest stock of long stub ends, stainless steel long stub end, carbon steel long stub end, nickel alloy long stub end, alloy steel long stub end, monel long stub end, copper long stub end in all dimensions.
- Butt weld Long Stub End Specifications
- Butt weld Long Stub End Materials and Grade
- Why Choose M P Jain Tubing Solutions LLP
- Butt weld Long Stub End Price in India
- Butt weld Long Stub End Dimension
- Butt weld Long Stub End – ANSI 16.9 Tolerances
- Butt weld Long Stub End Application Industries
- Cities We Export Butt weld Long Stub End
- Countries We Export Butt weld Long Stub End
ANSI/ASME B16.9 Butt weld Long Stub End Specifications
Type | Butt weld (BW) |
Standards | ASME / ANSI – B 16.9 ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’ API 590-605 ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’ ASME B16.25 – ‘Buttwelding Ends’ ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and Returns’ MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’ |
Dimension | ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313 |
Thickness | Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc. |
Schedule | Sch 5 TO Sch XXS. |
Size | 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”) |
ANSI/ASME B16.9 Butt weld Long Stub End Materials and Grade
Stainless Steel Butt weld Long Stub End:
- ASTM A403 WP316/316L
- ASTM A403 WP304/304L
- ASTM A182 F316L, 304L
- DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Carbon Steel Butt weld Long Stub End:
- ASTM A234 Gr. WPB
- ASTM A420 Gr. WPL6
- ASTM A105
- ASTM A350 Gr. LF2
Nickel Alloy Butt weld Long Stub End:
- Monel 400 & 500
- Inconel 600 & 625
- Incolloy 800, 825
- Hastelloy C22, C276
- Hastelloy
- Nickel
- Monel
- Inconel
- Alloy20
- Copper Nickel
- Cupro-Nickel 90/10
- Cupro-Nickel 70/30
Alloy Steel Butt weld Long Stub End:
- ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91
Why Choose M P Jain Tubing Solutions LLP
M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Long Stub End in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Long Stub End. We keep intensive stock of Long Neck Stub End Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.
We are committed to on-time delivery of ANSI B16.9 Long Stub End. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Long Stub End Fittings using high quality of raw materials and manufacture by our experts team.
How we manufactured pipe fittings:
- Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
- Selection of raw material: metal; plate or pipe.
- Cutting
- Heating.
- Forming.
- Welding: for fittings that are not simple elbows, returns, bends, long stub end or cap.
- Inspection and tests: according to standards and client requirements.
- Coating (if required).
- Preparation of documentation.
- Shipping.
ANSI/ASME B16.9 Butt weld Long Stub End Price List
Following is ANSI/ASME B16.9 Butt weld Long Stub End price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials | Price Range | Unit |
---|---|---|
Butt Weld Long Stub End | $4.00-$35.00 | USD/Piece |
Butt Weld Sanitary Long Neck Stub End | $0.10-$20.00 | USD/Piece |
1″ ASME long type butt weld 304 stub end | $6.10-$7.60 | USD/Kilogram |
Stainless Steel long stub end | $1.00-$100.00 | USD/Piece |
carbon steel long pipe Stub End ANSI B16.9 | $2.03-$53.00 | USD/Piece |
copper nickel pipe long stub end | $1.00-$100.00 | USD/Piece |
ASME B16.9 long pattern schedule 40s Stub end | $2.00-$20.00 | USD/Piece |
1/2 1 2 inch Long pattern duplex steel stub end | $1.00-$40.00 | USD/Piece |
Alloy Steel Long Neck Stub End | $4.00-$6.00 | USD/Piece |
Sch10s Pure Nickel Long Stub Ends For Industrial | $6.00-$1000.00 | USD/Piece |
gr2 long type 3″ titanium stub end | $12.00-$136.00 | USD/Piece |
Reference:alibaba
ASME B16.9 Butt weld Long Stub End Dimensions:
Nominal Pipe Size | Outside diameter of barrel |
Length (F) | Radius (R) | Diameter (G) | ||
---|---|---|---|---|---|---|
Minimum | Maximum | Long Pattern |
Short Pattern |
|||
1/2" | 20.5 | 22.8 | 76 | 51 | 3 | 35 |
3/4" | 25.9 | 28.1 | 76 | 51 | 3 | 43 |
1" | 32.6 | 35.0 | 102 | 51 | 3 | 51 |
1 1/4" | 41.4 | 43.6 | 102 | 51 | 5 | 64 |
1 1/2" | 47.5 | 49.9 | 102 | 51 | 6 | 74 |
2" | 59.5 | 62.4 | 152 | 64 | 8 | 92 |
2 1/2" | 72.2 | 75.3 | 152 | 64 | 8 | 105 |
3" | 88.1 | 91.3 | 152 | 64 | 10 | 127 |
3 1/2" | 100.8 | 104.0 | 152 | 76 | 10 | 140 |
4" | 113.5 | 116.7 | 152 | 76 | 11 | 157 |
5" | 140.5 | 144.3 | 203 | 76 | 11 | 186 |
6" | 167.5 | 171.3 | 203 | 89 | 13 | 216 |
8" | 218.3 | 222.1 | 203 | 102 | 13 | 270 |
10" | 272.3 | 277.2 | 254 | 127 | 13 | 324 |
12" | 323.1 | 328.0 | 254 | 152 | 13 | 381 |
14" | 354.8 | 359.9 | 305 | 152 | 13 | 413 |
16" | 405.6 | 411.0 | 305 | 152 | 13 | 470 |
18" | 456.0 | 462.0 | 305 | 152 | 13 | 533 |
20" | 507.0 | 514.0 | 305 | 152 | 13 | 584 |
22" | 558.0 | 565.0 | 305 | 152 | 13 | 641 |
24" | 609.0 | 616.0 | 305 | 152 | 13 | 692 |
Butt weld Long Stub End – ANSI B16.9 Tolerances:
DIMENSIONAL TOLERANCES – LAP JOINT STUB ENDS | ||||||
---|---|---|---|---|---|---|
For all fittings | Stub Ends | |||||
Nominal Pipe Size (NPS) | Outside Ø at Bevel | Indide Ø at End | Wall Thickness t / t1 |
O.D. of Lap G | Fillet Radius of Lap – R | Overall Length. – F |
1/2 a 2 1/2 | 1 | 0,8 | Not | +0 -1 | +0 -1 | 2 |
3 a 3 1/2 | 1 | 1,6 | less | +0 -1 | +0 -1 | 2 |
4 | +2 -1 | 1,6 | than | +0 -1 | +0 -2 | 2 |
5 a 6 | +3 -1 | 1,6 | 87,50% | +0 -1 | +0 -2 | 2 |
8 | 2 | 1,6 | of nominal | +0 -1 | +0 -2 | 2 |
10 | +4 -3 | 3,2 | tickness | +0 -2 | +0 -2 | 2 |
12 to 18 | +4 -3 | 3,2 | +0 -2 | +0 -2 | 3 | |
20 a 24 | +6 -5 | 4,8 | +0 -2 | +0 -2 | 3 | |
26 a 30 | +7 -5 | 4,8 | ||||
32 a 48 | +7 -5 | 4,8 |
ANSI/ASME B16.9 Butt weld Long Stub End Application
Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld Long Stub End and supplying to various core industries likeChemicals Fertilizers Industries
Heat Exchanger
Instrumentation
Nuclear Thermal Industries
Oil Gas Industries
Pharmacy Surgical Industries
Refineries Petrochemicals
Water Gas Piping Systems
