What is 90 Degree Long Radius Elbow?

Fittings that change direction in a piping system are called elbows. The directional change is given in degree such as 45 or 90. 90 degree long radius elbow has the center line of elbow at 1.5 x NPS from eblow end. 3R elbow has center line at 3 x NPS from elbow end.

90 Degree Long Radius Elbow Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Short Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

90 Degree Long Radius Elbow Materials and Grade

Stainless Steel 90 degree Long Radius Elbow:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel 90 degree Long Radius Elbow:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy 90 degree Long Radius Elbow:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy steel 90 degree Long Radius Elbow:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of 90 degree long radius elbow in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of ANSI/ASME B16.9 90° Long Radius Elbow. We keep intensive stock of long radius 90 degree elbow to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of both seamless and welded 90 deg long radius elbow. We have over 4 decades of experience in manufacturing of ASME B16.9 Butt weld 90 degree Long Radius Elbow using high quality of raw materials and using latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

90 Degree Long Radius Elbow Price List

Following is 90 Degree Long Radius Elbow price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
ANSI B16.5 CS long radius butt weld 90 degree elbow $1.00-$300.00 USD/Piece
90 degree seamless long and short radius elbow $0.10-$500.00 USD/Piece
ASME B16.9 Butt weld 90 degree Long Radius Elbow $2.40-$2.50 USD/Piece
high precision 90 degree long radius ss elbow $10.00-$999.00 USD/Piece
Long Radius bw 90 degree Elbow $10.00-$100.00 USD/Piece
long radius 90 degree alloy steel elbow $1.00-$10.00 USD/Piece
Butt Welding Seamless Pipe Fitting 90 Degree Long Radius Elbow $2.50-$19.20 USD/Piece
90 degree sch40 long radius carbon steel elbow $0.60-$50.00 USD/Piece
A234 WPB 90 degree long radius pipe fittings elbow $0.50-$1.00 USD/Kilogram
3 inch sch 80 butt welded long radius 90 degree elbows $0.50-$400.00 USD/Piece
ASTM A403 90 Degree Long Radius Elbow $1.00-$100.00 USD/Piece
long radius 1.5 D mild steel 90 degree elbow $1.00-$50.00 USD/Piece
sanitary 90 deg long welded elbow $3.50-$1500.00 USD/Piece
stainless steel 90 degree Long Radius Elbow $1.00-$30.00 USD/Piece
Long Radius 90 Degree Elbow, Schedule 10 $5.00-$75.00 USD/Piece
6” 90 Degree Long Radius Elbow $3.65-$3.66 USD/Piece
steel 90 degree long radius elbow $3.00-$320.00 USD/Piece
90 degree long radius sch40 20 elbow $1.00-$3.00 USD/Piece

Reference:alibaba

90 Degree Long Radius Elbow Dimensions:

Butt weld 90 degree Long Radius Elbow Dimensions
NPS O.D.
D
90 degrees
Long Radius
Center-to-End
A
45 degrees
Long Radius
Center-to-End
B
90 degrees
3D
Center-to-End
A
45 degrees
3D
Center-to-End
B
1/2 21.3 38 16
3/4 26.7 38 19 57 24
1 33.4 38 22 76 31
42.2 48 25 95 39
48.3 57 29 114 47
2 60.3 76 35 152 63
73 95 44 190 79
3 88.9 114 51 229 95
101.6 133 57 267 111
4 114.3 152 64 305 127
5 141.3 190 79 381 157
6 168.3 229 95 457 189
8 219.1 305 127 610 252
10 273 381 159 762 316
12 323.8 457 190 914 378
14 355.6 533 222 1067 441
16 406.4 610 254 1219 505
18 457 686 286 1372 568
20 508 762 318 1524 632
22 559 838 343 1676 694
24 610 914 381 1829 757
26 660 991 406 1981 821
28 711 1067 438 2134 883
30 762 1143 470 2286 964
32 813 1219 502 2438 1010
34 864 1295 533 2591 1073
36 914 1372 565 2743 1135
38 965 1448 600 2896 1200
40 1016 1524 632 3048 1264
42 1067 1600 660 3200 1326
44 1118 1676 695 3353 1389
46 1168 1753 727 3505 1453
48 1219 1829 759 3658 1516

90 Degree Long Radius Elbow Dimensional Tolerance

DIMENSIONAL TOLERANCES – ELBOWS
For all fittings Elbows 90/45 deg 180° Returns
Nominal Pipe Size (NPS) Outside Ø
at Bevel
Inside Ø
at End
Wall Thickness
t / t1
Center to End Dim. A-B-C-M Center to Center Dim.
O
Back to Face Dim.
K
Align- ment of Ends
U
1/2 a 2 1/2 1 0,8 Not 2 7 7 1
3 a 3 1/2 1 1,6 less 2 7 7 1
4 +2 -1 1,6 than 2 7 7 1
5 a 6 +3 -1 1,6 87,50% 2 7 7 1
8 2 1,6 of nominal 2 7 7 1
10 +4 -3 3,2 thickness 2 7 7 2
12 a 18 +4 -3 3,2 3 10 7 2
20 a 24 +6 -5 4,8 3 10 7 2
26 a 30 +7 -5 4,8 3 ….. ….. …..
32 a 48 +7 -5 4,8 5 ….. ….. …..

90 Degree Long Radius Elbow Angularity Tolerances

Angularity Tolerances
ND Max off angle Max off plane
Q P
1/2 a 4 1 2
5 a 8 2 4
10 a 12 3 5
14 a 16 3 7
18 a 24 4 10
26 a 30 5 10
32 a 42 5 13
44 a 48 5 20

Long Radius 90 Degree Buttweld Elbows Weight in KG

WEIGHTS OF FITTINGS
NPS
inches
ELBOWS
LR 90°
ELBOWS
SR 90°
Sch.
5S
Sch.
10S
Sch.
40S
Sch.
80S
Sch.
5S
Sch.
10S
Sch.
40S
Sch.
80S
1/2 0.05 0.06 0.08 0.10 0.03 0.04 0.05 0.07
3/4 0.06 0.07 0.09 0.11 0.04 0.05 0.06 0.07
1 0.09 0.15 0.18 0.20 0.06 0.10 0.12 0.13
1 1/4 0.13 0.20 0.25 0.35 0.09 0.13 0.17 0.12
1 1/2 0.18 0.30 0.40 0.50 0.12 0.20 0.27 0.33
2 0.30 0.50 0.70 0.90 0.20 0.33 0.47 0.60
2 1/2 0.60 0.85 1.35 1.80 0.40 0.60 0.90 1.20
3 0.90 1.30 2.00 2.90 0.60 0.90 1.35 1.90
4 1.40 2.00 4.00 5.90 0.90 1.35 2.65 3.90
5 2.90 3.60 6.50 9.70 1.95 2.40 4.35 6.50
6 4.00 5.00 10.5 16.0 2.70 3.35 7.00 10.5
8 7.40 10.0 21.5 33.5 4.90 6.70 14.5 22.5
10 13.6 16.8 38.5 52.5 9.10 11.2 25.6 35.0
12 23.4 27.0 59.0 79.0 15.6 18.0 39.5 53.0
14 29.0 35.0 70.0 94.0 19.3 23.5 47.0 63.0
16 41.3 47.0 95.0 125 27.5 31.5 63.5 84.0
18 51.8 59.0 120 158 34.5 39.5 80.0 105
20 73.0 85.0 146 194 49.0 57.0 98.0 129
24 122 140 210 282 82.0 94.0 140 188
Approximate weights in kg, density 8 kg/dm3

ANSI/ASME B16.9 90° Long Radius Elbow Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of 90 Degree Long Radius Elbow and supplying to various core industries like
Chemicals Fertilizers Industries
