Butt weld ASME B16.9 Concentric Reducer Manufacturer

Leading ANSI/ASME B16.9 Butt weld Concentric Reducer Manufacturers and Authoritative SS Concentric Reducer Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Concentric Reducer Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld concentric reducer fittings we are providing high-quality buttweld concentric reducer pipe fitting at best price in India.

We keep the largest stock of stainless steel concentric reducer, carbon steel concentric reducer, nickel alloy concentric reducer, alloy steel concentric reducer, monel concentric reducer, copper concentric reducer, concentric reducer fitting in all dimensions.

Contact Us
WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD CONCENTRIC REDUCER / STAINLESS STEEL BUTT WELD CONCENTRIC REDUCER / DUPLEX STEEL BUTT WELD CONCENTRIC REDUCER / CARBON STEEL BUTT WELD CONCENTRIC REDUCER / ALLOY STEEL BUTT WELD CONCENTRIC REDUCER / HASTELLOY STEEL BUTT WELD CONCENTRIC REDUCER / MONEL STEEL BUTT WELD CONCENTRIC REDUCER / INCONEL STEEL BUTT WELD CONCENTRIC REDUCER / TITANIUN STEEL BUTT WELD CONCENTRIC REDUCER / SUPER DUPLEX STEEL BUTT WELD CONCENTRIC REDUCER / INCOLOY STEEL BUTT WELD CONCENTRIC REDUCER / ALLOY 20 BUTT WELD CONCENTRIC REDUCER / 254 SMO BUTT WELD CONCENTRIC REDUCER/ COPPER NICKEL STEEL BUTT WELD CONCENTRIC REDUCER
ANSI/ASME B16.9 Butt weld Concentric Reducer Exporter in India

ANSI/ASME B16.9 Butt weld Concentric Reducer Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Concentric Reducer Materials and Grade

Stainless Steel Butt weld Concentric Reducer:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Concentric Reducer:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Concentric Reducer:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Concentric Reducer:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Concentric Reducer in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Concentric Reducer. We keep intensive stock of Concentric Reducer Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI Concentric Reducer. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Concentric Reducer Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, concentric reducer or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Concentric Reducer Price List

Following is ANSI/ASME B16.9 Butt weld Concentric Reducer price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Butt Weld Pipe Fittings Concentric Reducer $10.00-$50.00 USD/Piece
A234 WPB SCH40 SCH80 butt weld Concentric Reducer $0.20-$1000.00 USD/Piece
butt weld low pressure concentric reducer $1.00-$100.00 USD/Piece
Concentric Reducer Duplex Pipe Fitting Butt Weld $72.00-$75.00 USD/Piece
stainless steel butt welding concentric reducer $0.40-$40.00 USD/Piece
ANSI B16.9 Butt Welded Stainless steel concentric reducer $1.00-$100.00 USD/Piece
48.3mm x 42mm concentric long reducer $6.10-$7.60 USD/Piece
butt welded seamless SCH40 steel pipe concentric reducers $0.20-$85.00 USD/Piece
ASME B16.9 butt welded carbon steel concentric reducers $1.00-$10.00 USD/Piece
ANSI CS Seamless Butt Welded Concentric Reducer $50.00-$60.00 USD/Piece
Concentric Reducer A403 Seamless Butt Welding 5″*3″ $10.26 USD/Piece
Hot Pipe Fittings butt welded SS concentric reducer $0.50-$7.30 USD/Piece
6 inch SS butt welded fitting concentric reducer $600.00-$800.00 USD/Ton

Reference:alibaba

ASME B16.9 Butt weld Concentric Reducer Dimensions:

Nominal Diameter Outside Diameter
End to End
D1*D2
DN NPS Series A Series B H
20×15 3/4×1/2 26.9×21.3 25×18 38
20×10 3/4×3/8 26.9×17.3 25×14 38
25×20 1×3/4 33.7×26.9 32×25 51
25×15 1×1/2 33.7×21.3 32×18 51
32×25 1.1/4×1 42.4×33.7 38×32 51
32×20 1.1/4×3/4 42.4×26.9 38×25 51
32×15 1.1/4×1/2 42.4×21.3 38×18 51
40×32 1.1/2×1.1/4 48.3×42.4 45×38 64
40×25 1.1/2×1 48.3×33.7 45×32 64
40×20 1.1/2×3/4 48.3×26.9 45×25 64
40×15 1.1/2×1/2 48.3×21.3 45×18 64
50×40 2×1.1/2 60.3×48.3 57×45 76
50×32 2×1.1/4 60.3×42.4 57×38 76
50×25 2×1 60.3×33.7 57×32 76
50×20 2×3/4 60.3×26.9 57×25 76
65×50 2.1/2×2 73.0×60.3 76×57 89
65×40 2.1/2×1.1/2 73.0×48.3 76×45 89
65×32 2.1/2×1.1/4 73.0×42.4 76×38 89
65×25 2.1/2×1 73.0×33.7 76×32 89
80×65 3×2.1/2 88.9×73.0 89×76 89
80×50 3×2 88.9×60.3 89×57 89
80×40 3×1.1/2 88.9×48.3 89×45 89
80×32 3×1.1/4 88.9×42.4 89×38 89
90×80 3.1/2×3 101.6×88.9 102
90×65 3.1/2×2.1/2 101.6×73.0 102
90×50 3.1/2×2 101.6×60.3 102
90×40 3.1/2×1.1/2 101.6×48.3 102
90×32 3.1/2×1.1/4 101.6×42.4 102
100×90 4×3.1/2 114.3×101.6 102
100×80 4×3 114.3×88.9 108×89 102
100×65 4×2.1/2 114.3×73.0 108×76 102
100×50 4×2 114.3×60.3 108×57 102
100×40 4×1.1/2 114.3×48.3 108×45 102
125×100 5×4 141.3×114.3 133×108 127
125×90 5×3.1/2 141.3×101.6 127
125×80 5×3 141.3×88.9 133×89 127
125×65 5×2.1/2 141.3×73.0 133×76 127
125×50 5×2 141.3×60.3 133×57 127
150×125 6×5 168.3×141.3 159×133 140
150×100 6×5 168.3×114.3 159×108 140
150×90 6×3.1/2 168.3×101.6 140
150×80 6×3 168.3×88.9 159×89 140
150×65 6×2.1/2 168.3×73.0 159×76 140
200×150 8×6 219.1×168.3 219×159 152
200×125 8×5 219.1×141.3 219×133 152
200×100 8×4 219.1×114.3 219×108 152
200×90 8×3.1/2 219.1×101.6 152
250×200 10×8 273.0×219.1 273×219 178
250×150 10×6 273.0×168.3 273×159 178
250×125 10×5 273.0×141.3 273×133 178
250×100 10×4 273.0×114.3 273×108 178
300×250 12×10 323.9×273.1 325×273 203
300×200 12×8 323.9×219.1 325×219 203
300×150 12×6 323.9×168.3 325×159 203
300×125 12×5 323.9×141.3 325×133 203
350×300 14×12 355.6×323.9 377×325 330
350×250 14×10 355.6×273.0 377×273 330
350×200 14×8 355.6×219.1 377×219 330
350×150 14×6 355.6×168.3 377×159 330
400×350 16×14 406.4×355.6 426×377 356
400×300 16×12 406.4×323.9 426×325 356
400×250 16×10 406.4×273.0 426×273 356
400×200 16×8 406.4×219.1 426×219 356
450×400 18×16 457×406.4 478×426 381
450×350 18×14 457×355.6 478×377 381
450×300 18×12 457×323.9 478×325 381
450×250 18×10 457×273.0 478×273 381
500×450 20×18 508×457 529×478 508
500×400 20×16 508×406.4 529×426 508
500×350 20×14 508×355.6 529×377 508
500×300 20×12 508×323.9 529×325 508
550×500 22×20 559×508 508
550×450 22×18 559×457 508
550×400 22×16 559×406.4 508
550×350 22×14 559×355.6 508
600×550 24×22 610×559 508
600×500 24×20 610×508 630×529 508
600×450 24×18 610×457 630×478 508
600×400 24×22 610×406.4 630×426 508
650×600 26×24 660×610 610
650×550 26×22 660×559 610
650×500 26×20 660×508 610
650×450 26×18 660×457 610
700×650 28×26 711×660 610
700×600 28×24 711×610 720×630 610
700×550 28×22 711×559 610
700×500 28×20 711×508 720×530 610
750×700 30×28 762×711 610
750×650 30×26 762×660 610
750×600 30×24 762×610 610
750×550 30×22 762×559 610
800×750 32×30 813×762 610
800×700 32×28 813×711 820×720 610
800×650 32×26 813×660 610
800×600 32×24 813×610 820×630 610
850×800 34×32 864×813 610
850×750 34×30 864×762 610
850×700 34×28 864×711 610
850×650 34×26 864×660 610
900×850 36×34 914×864 610
900×800 36×32 914×813 920×820 610
900×750 36×30 914×762 610
900×700 36×28 914×711 920×720 610
950×900 38×36 965×914 610
950×850 38×34 965×864 610
950×800 38×32 965×813 610
950×750 38×30 965×762 610
1000×950 40×38 1016×965 610
1000×900 40×36 1016×914 1020×920 610
1000×850 40×34 1016×864 610
1000×800 40×32 1016×813 1020×820 610
1050×1000 42×40 1067×1016 610
1050×950 42×38 1067×965 610
1050×900 42×36 1067×914 610
1050×850 42×34 1067×864 610
1100×1050 44×42 1118×1067 610
1100×1000 44×40 1118×1016 1120×1020 610
1100×950 44×38 1118×965 610
1100×900 44×36 1118×914 1220×920 610
1150×1100 46×44 1168×1118 711
1150×1050 46×42 1168×1067 711
1150×1000 46×40 1168×1016 711
1150×950 46×38 1168×965 711
1200×1150 48×46 1220×1168 711
1200×1100 48×44 1220×1118 1220×1120 711
1200×1050 48×42 1220×1067 711
1200×1000 48×40 1220×1016 1220×1020 711

ANSI/ASME B16.9 Butt weld Concentric Reducer Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld Concentric Reducer and supplying to various core industries like
Chemicals Fertilizers Industries
Chemicals Fertilizers Industries
Heat Exchanger
Heat Exchanger
Instrumentation
Instrumentation
Nuclear Thermal Industries
Nuclear Thermal Industries
Oil Gas Industries
Oil Gas Industries
Pharmacy Surgical Industries
Pharmacy Surgical Industries
Refineries Petrochemicals
Refineries Petrochemicals
Water Gas Piping Systems
Water Gas Piping Systems
