Leading ASME B16.9 Reducing Outlet Tees and Reducing Outlet Crosses Manufacturers and Authoritative SS Reducing Outlet Tees and Reducing Outlet Crosses Supplier in India and Overseas.

ASME B16.9 reducing outlet tees and reducing outlet crosses Manufacturers in India

As a leading manufacturer, stockist, and exporters of ASME B16.9 reducing outlet tees and reducing outlet crosses we are providing high-quality reducing outlet tees and reducing outlet crosses at best price in India.

We keep the largest stock of Stainless Steel Reducing Outlet Tees and Reducing Outlet Crosses, Nickel Alloy Reducing Outlet Tees and Reducing Outlet Crosses, Carbon Steel Reducing Outlet Tees and Reducing Outlet Crosses, Inconel Reducing Outlet Tees and Reducing Outlet Crosses.

Contact Us
WE ARE MANUFACTURING ASME B16.9 REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / STAINLESS STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / DUPLEX STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / CARBON STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / ALLOY STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / HASTELLOY STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / MONEL STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / INCONEL STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / TITANIUN STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / SUPER DUPLEX STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / INCOLOY STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / ALLOY 20 REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES / 254 SMO REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES/ COPPER NICKEL STEEL REDUCING OUTLET TEES AND REDUCING OUTLET CROSSES
ASME B16.9 reducing outlet tees and reducing outlet crosses Exporter in India

ASME B16.9 Reducing Outlet Tees and Reducing Outlet Crosses Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless Steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ASME B16.9 Reducing Outlet Tees and Reducing Outlet Crosses Materials and Grade

Stainless Steel Buttweld Reducing Outlet Tees and Reducing Outlet Crosses:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Buttweld Reducing Outlet Tees and Reducing Outlet Crosses:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Buttweld Reducing Outlet Tees and Reducing Outlet Crosses:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Buttweld Reducing Outlet Tees and Reducing Outlet Crosses:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ASME B16.9 reducing outlet tees and reducing outlet crosses in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of SS Reducing Outlet Tees and Reducing Outlet Crosses. We keep intensive stock of Reducing Outlet Tees and Reducing Outlet Crosses to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of Reducing Outlet Tees and Crosses. We have over 4 decades of experience in manufacturing of both seamless & welded Reducing Outlet Tees and Crosses using high quality of raw materials and latest machinery and under the guidance of experts.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ASME B16.9 Reducing Outlet Tees and Reducing Outlet Crosses Price List

Following is ASME B16.9 reducing outlet tees and reducing outlet crosses price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
reducing outlet tee $0.10-$26.00 USD/Piece
Stainless steel reducing outlet tee in pipe $1.50-$30.00 USD/Piece
reducer black iron black side outlet tee $1.50-$50.00 USD/Piece
Seamless Welding Reducing Outlet Tees $1630.00-$1660.00 USD/Ton
Butt welding reducing outlet pipe tee $1.00-$20.00 USD/Piece
Butt weld STD Sch 40 Reducing outlet Tees $4.00-$8.00 USD/Piece
ASME/ANSI B16.9 Gr2 titanium reducing outlet tees $60.00-$100.00 USD/Piece
Reducing Outlet Tee, SCH 10S $0.50-$120.00 USD/Piece
A234 WP92 Reducing Outlet Tees and Crosses $11.00-$12.00 USD/Piece
Carton steel reducing outlet tees $1.00-$200.00 USD/Piece
Butt-welding Reducing Outlet Tees and Crosses $8.00-$25.00 USD/Piece

Reference:alibaba

Buttweld Reducing Outlet Tees and Reducing Outlet Crosses Dimensions:

Nominal   Pipe   Size   (NPS) DN Outlet Diameter at Bevel
Center- to-End
Run Outlet Run.C Outlet. M[Notes(1)]
1/2*1/2*3/8 15*15*10 21.3 17.3 25 25
1/2*1/2*1/4 15*15*8 21.3 13.7 25 25
3/4*3/4*1/2 20*20*15 26.7 21.3 29 29
3/4*3/4*3/8 20*20*10 26.7 17.3 29 29
1*1*3/4 25*25*20 33.4 26.7 38 38
1*1*1/2 25*25*15 33.4 21.3 38 38
1-1/4*1-1/4*1 32*32*25 42.2 33.4 48 48
1-1/4*1-1/4*3/4 32*32*20 42.2 26.7 48 48
1-1/4*1-1/4*1/2 32*32*15 42.2 21.3 48 48
1-1/2*1-1/2*1-1/4 40*40*32 48.3 42.2 57 57
1-1/2*1-1/2*1 40*40*25 48.3 33.4 57 57
1-1/2*1-1/2*3/4 40*40*20 48.3 26.7 57 57
1-1/2*1-1/2*1/2 40*40*15 48.3 21.3 57 57
2*2*1-1/2 50*50*40 60.3 48.3 64 60
2*2*1-1/4 50*50*32 60.3 42.2 64 57
2*2*1 50*50*25 60.3 33.4 64 51
2*2*3/4 50*50*20 60.3 73.0 64 44
2-1/2*2-1/2*2 65*65*50 73.0 60.3 76 70
2-1/2*2-1/2*1-1/2 65*65*40 73.0 48.3 76 67
2-1/2*2-1/2*1-1/4 65*65*32 73.0 42.2 76 64
2-1/2*2-1/2*1 65*65*25 73.0 88.9 76 57
3*3*2-1/2 80*80*65 88.9 73.0 86 83
3*3*2 80*80*50 88.9 60.3 86 76
3*3*1-1/2 80*80*40 88.9 48.3 86 73
3*3*1-1/4 80*80*32 88.9 101.6 86 70
3-1/2*3-1/2*3 90*90*80 101.6 88.9 95 92
3-1/2*3-1/2*2-1/2 90*90*65 101.6 73.0 95 89
3-1/2*3-1/2*2 90*90*50 101.6 60.3 95 83
3-1/2*3-1/2*1-1/2 90*90*40 101.6 48.3 95 79
4*4*3-1/2 100*100*90 114.3 101.6 105 102
4*4*3 100*100*80 114.3 88.9 105 98
4*4*2-1/2 100*100*65 114.3 73.0 105 95
4*4*2 100*100*50 114.3 60.3 105 89
4*4*1-1/2 100*100*40 114.3 48.3 105 86
5*5*4 125*125*100 141.3 114.3 124 117
5*5*3-1/2 125*125*90 141.3 101.6 124 114
5*5*3 125*125*80 141.3 88.9 124 111
5*5*2-1/2 125*125*65 141.3 73.6 124 108
5*5*2 125*125*50 141.3 60.3 124 105

Reducing Outlet Tees and Reducing Outlet Crosses Dimensions Tolerance:

Nominal Pipe Size 1/2 to 2½ 3 to 3½ 4 5 to 8 10 to 18 20 to 24 26 to 30 32 to 48
Outside Diameter
at Bevel (D)		 + 1.6
– 0.8		 1.6 1.6 + 2.4
– 1.6		 + 4
– 3.2		 + 6.4
– 4.8		 + 6.4
– 4.8		 + 6.4
– 4.8
Inside Diameter at End 0.8 1.6 1.6 1.6 3.2 4.8 + 6.4
– 4.8		 + 6.4
– 4.8
Center-to-End (C / M) 2 2 2 2 2 2 3 5
Wall Thickness (t) Not less than 87.5% of Nominal Wall Thickness

GENERAL NOTE: All dimensions are in millimeter.
Note: Outlet dimension M for run sizes NPS 14(DN350) and larger is recommended but not required.
