Leading ANSI/ASME B16.9 Straight Tees and Crosses Manufacturers and Authoritative SS Straight Tees and Crosses Supplier in India and Overseas.
As a leading manufacturer, stockist, and exporters of ASME B16.9 Straight Tees and Crosses we are providing high-quality Straight Tees and Crosses at best price in India.
We keep the largest stock of Stainless Steel Straight Tees and Crosses, Butt weld Straight Tees and Crosses, ASME B16.9 Straight Tees and Crosses, Nickel Alloy Straight Tees and Crosses, Alloy steel Straight Tees and Crosses, Carbon Steel Straight Tees and Crosses, Monel Straight Tees and Crosses, Inconel Straight Tees and Crosses.
- ASME B16.9 Straight Tees and Crosses Specifications
- ASME B16.9 Straight Tees and Crosses Materials and Grade
- Why Choose M P Jain Tubing Solutions LLP
- ASME B16.9 Straight Tees and Crosses Price in India
- ASME B16.9 butt welded Straight Tees Dimension
- ASME B16.9 ASME B16.9 Straight Tees Dimensions
- ASME B16.9 Buttweld Crosses Dimensions
- ASME B16.9 Straight Tees and Crosses Application Industries
- Cities We Export ASME B16.9 Straight Tees and Crosses
- Countries We Export ASME B16.9 Straight Tees and Crosses
ANSI/ASME B16.9 Straight Tees and Crosses Specifications
| Type | Butt weld (BW) |
| Standards | ASME / ANSI – B 16.9 ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings’ API 590-605 ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’ ASME B16.25 – ‘Buttwelding Ends’ ASME B16.28 – ‘Wrought Steel Buttwelding Long Radius Elbows and Returns’ MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’ |
| Dimension | ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313 |
| Thickness | Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc. |
| Schedule | Sch 5 TO Sch XXS. |
| Size | 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”) |
ANSI/ASME B16.9 Straight Tees and Crosses Materials and Grade
Stainless Steel ANSI/ASME B16.9 Straight Tees and Crosses:
- ASTM A403 WP316/316L
- ASTM A403 WP304/304L
- ASTM A182 F316L, 304L
- DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Carbon Steel ANSI/ASME B16.9 Straight Tees and Crosses:
- ASTM A234 Gr. WPB
- ASTM A420 Gr. WPL6
- ASTM A105
- ASTM A350 Gr. LF2
Nickel Alloy ANSI/ASME B16.9 Straight Tees and Crosses:
- Monel 400 & 500
- Inconel 600 & 625
- Incolloy 800, 825
- Hastelloy C22, C276
- Hastelloy
- Nickel
- Monel
- Inconel
- Alloy20
- Copper Nickel
- Cupro-Nickel 90/10
- Cupro-Nickel 70/30
Alloy Steel ANSI/ASME B16.9 Straight Tees and Crosses:
- ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91
Why Choose M P Jain Tubing Solutions LLP
M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Straight Tees and Crosses in Mumbai, India since 1972. We are ISO 9001:2015 certified company and most trusted suppliers of SS Straight Tees and Crosses. We keep intensive stock of Straight Tees and Crosses to fulfil urgent requirements of our clients at reasonable prices.
We are committed to on-time delivery of Straight Tees and Crosses. We have over 4 decades of experience in manufacturing of both seamless & welded Straight Tees and Crosses using high quality of raw materials and latest machinery and under the guidance of experts.
How we manufactured pipe fittings:
- Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
- Selection of raw material: metal; plate or pipe.
- Cutting
- Heating.
- Forming.
- Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
- Inspection and tests: according to standards and client requirements.
- Coating (if required).
- Preparation of documentation.
- Shipping.
ANSI/ASME B16.9 Straight Tees and Crosses Price List
Following is ANSI/ASME B16.9 Straight Tees and Crosses price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
| Materials | Price Range | Unit |
|---|---|---|
| butt welded Straight Tees and Crosse | $1.00-$3000.00 | USD/Piece |
| Titanium Straight Tees and Crossed | $5.00-$100.00 | USD/Piece |
| SS Pipe Straight Tee Fittings Tee/ Cross | $1.50-$150.00 | USD/Piece |
| Butt-welding Straight Tees and Crosses 304/316L | $8.00-$25.00 | USD/Piece |
| brass material straight tee and cross | $0.12-$2.00 | USD/Piece |
| Gr1 Gr2 titanium butt-welding straight tee and cross | $120.00-$140.00 | USD/Piece |
| Straight Welding Union Tee Cross | $1.80-$5.00 | USD/Piece |
| High Pressure Carbon Steel Pipe Straight Tee And Cross | $0.10-$90.00 | USD/Piece |
| SA234 WPB CS Straight pipe cross | $2.00-$1500.00 | USD/Piece |
| Copper Pipe Fitting Reducing Straight Elbow Tee Cross | $1.40-$90.00 | USD/Piece |
| ASME B16.9 Buttweld Straight Tee & Cross | $6.50-$6.90 | USD/Piece |
Reference:alibaba
Buttweld ANSI/ASME B16.9 butt welded Straight Tees Dimensions:
| NPS | O.D. D |
Center-to-End C |
Center-to-End M |
|---|---|---|---|
| 1/2 | 21.3 | 25 | 25 |
| 3/4 | 26.7 | 29 | 29 |
| 1 | 33.4 | 38 | 38 |
| 1¼ | 42.2 | 48 | 48 |
| 1½ | 48.3 | 57 | 57 |
| 2 | 60.3 | 64 | 64 |
| 2½ | 73 | 76 | 76 |
| 3 | 88.9 | 86 | 86 |
| 3½ | 101.6 | 95 | 95 |
| 4 | 114.3 | 105 | 105 |
| 5 | 141.3 | 124 | 124 |
| 6 | 168.3 | 143 | 143 |
| 8 | 219.1 | 178 | 178 |
| 10 | 273 | 216 | 216 |
| 12 | 323.8 | 254 | 254 |
| 14 | 355.6 | 279 | 279 |
| 16 | 406.4 | 305 | 305 |
| 18 | 457 | 343 | 343 |
| 20 | 508 | 381 | 381 |
| 22 | 559 | 419 | 419 |
| 24 | 610 | 432 | 432 |
| 26 | 660 | 495 | 495 |
| 28 | 711 | 521 | 521 |
| 30 | 762 | 559 | 559 |
| 32 | 813 | 597 | 597 |
| 34 | 864 | 635 | 635 |
| 36 | 914 | 673 | 673 |
| 38 | 965 | 711 | 711 |
| 40 | 1016 | 749 | 749 |
| 42 | 1067 | 762 | 711 |
| 44 | 1118 | 813 | 762 |
| 46 | 1168 | 851 | 800 |
| 48 | 1219 | 889 | 838 |
ANSI/ASME B16.9 Straight Tees Dimensions Tolerance:
| Nominal Pipe Size | 1/2 to 2½ | 3 to 3½ | 4 | 5 to 8 | 10 to 18 | 20 to 24 | 26 to 30 | 32 to 48 |
|---|---|---|---|---|---|---|---|---|
| Outside Diameter at Bevel (D) |
+ 1.6 – 0.8 |
1.6 | 1.6 | + 2.4 – 1.6 |
+ 4 – 3.2 |
+ 6.4 – 4.8 |
+ 6.4 – 4.8 |
+ 6.4 – 4.8 |
| Inside Diameter at End | 0.8 | 1.6 | 1.6 | 1.6 | 3.2 | 4.8 | + 6.4 – 4.8 |
+ 6.4 – 4.8 |
| Center-to-End (C / M) | 2 | 2 | 2 | 2 | 2 | 2 | 3 | 5 |
| Wall Thickness (t) | Not less than 87.5% of Nominal Wall Thickness | |||||||
ANSI/ASME B16.9 Buttweld Crosses Dimensions:
| Nominal Pipe Size (NPS) | DN | Outside Diameter at Bevel | Center- to-End |
|
|---|---|---|---|---|
| Run.C | Outlet. M[Notes(1) and (2)] | |||
| 1/2 | 15 | 21.3 | 25 | 25 |
| 3/4 | 20 | 26.7 | 29 | 29 |
| 1 | 25 | 33.4 | 38 | 38 |
| 1-1/4 | 32 | 42.2 | 48 | 48 |
| 1-1/2 | 40 | 48.3 | 57 | 57 |
| 2 | 50 | 60.3 | 64 | 64 |
| 2-1/2 | 65 | 73.0 | 76 | 76 |
| 3 | 80 | 88.9 | 86 | 86 |
| 3-1/2 | 90 | 101.6 | 95 | 95 |
| 4 | 100 | 114.3 | 105 | 105 |
| 5 | 125 | 141.3 | 124 | 124 |
| 6 | 150 | 168.3 | 143 | 143 |
| 8 | 200 | 219.1 | 178 | 178 |
| 10 | 250 | 273.0 | 216 | 216 |
| 12 | 300 | 323.8 | 254 | 254 |
| 14 | 350 | 355.6 | 279 | 279 |
| 16 | 400 | 406.4 | 305 | 305 |
| 18 | 450 | 457 | 343 | 343 |
| 20 | 500 | 508 | 381 | 381 |
| 22 | 550 | 559 | 419 | 419 |
| 24 | 600 | 610 | 432 | 432 |
| 26 | 650 | 660 | 495 | 495 |
| 28 | 700 | 711 | 521 | 521 |
| 30 | 750 | 762 | 559 | 559 |
| 32 | 800 | 813 | 597 | 597 |
| 34 | 850 | 864 | 635 | 635 |
| 36 | 900 | 914 | 673 | 673 |
| 38 | 950 | 965 | 711 | 711 |
| 40 | 1000 | 1016 | 749 | 749 |
| 42 | 1050 | 1067 | 762 | 711 |
| 44 | 1100 | 1118 | 813 | 762 |
| 46 | 1150 | 1168 | 851 | 800 |
| 48 | 1200 | 1219 | 889 | 838 |
ANSI/ASME B16.9 Straight Tees and Crosses Application
Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Straight Tees and Crosses and supplying to various core industries like
Chemicals Fertilizers Industries
Heat Exchanger
Instrumentation
Nuclear Thermal Industries
Oil Gas Industries
Pharmacy Surgical Industries
Refineries Petrochemicals
Water Gas Piping Systems
