Leading ANSI/ASME B16.9 Butt weld End Cap Manufacturers and Authoritative Buttweld End Cap Supplier in India and Overseas.
As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt weld end cap, we are providing high-quality SS end cap at best price in India.
We keep the largest stock of stainless steel end cap, carbon steel end cap, nickel alloy end cap, alloy steel end cap, monel end cap in all dimensions.
- Butt weld End Cap Specifications
- Butt weld End Cap Materials and Grade
- Why Choose M P Jain Tubing Solutions LLP
- Butt weld End Cap Price in India
- Butt weld End Cap Dimension
- Butt weld End Cap Tolerances
- Butt weld End Cap Application Industries
- Cities We Export Butt weld End Cap
- Countries We Export Butt weld End Cap
ANSI/ASME B16.9 Butt weld End Cap Specifications
| Type | Butt weld (BW) |
| Standards | ASME / ANSI – B 16.9 ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’ API 590-605 ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’ ASME B16.25 – ‘Buttwelding Ends’ ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’ MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’ |
| Dimension | ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313 |
| Thickness | Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc. |
| Schedule | Sch 5 TO Sch XXS. |
| Size | 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”) |
ANSI/ASME B16.9 Butt weld End Cap Materials and Grade
Stainless Steel Butt weld End Cap:
- ASTM A403 WP316/316L
- ASTM A403 WP304/304L
- ASTM A182 F316L, 304L
- DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Carbon Steel Butt weld End Cap:
- ASTM A234 Gr. WPB
- ASTM A420 Gr. WPL6
- ASTM A105
- ASTM A350 Gr. LF2
Nickel Alloy Butt weld End Cap:
- Monel 400 & 500
- Inconel 600 & 625
- Incolloy 800, 825
- Hastelloy C22, C276
- Hastelloy
- Nickel
- Monel
- Inconel
- Alloy20
- Copper Nickel
- Cupro-Nickel 90/10
- Cupro-Nickel 70/30
Alloy Steel Butt weld End Cap:
- ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91
Why Choose M P Jain Tubing Solutions LLP
M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld End Cap in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Buttweld End Cap. We keep intensive stock of End Cap Fitting to fulfil urgent requirements of our clients at reasonable prices.
We are committed to on-time delivery of ANSI B16.9 End Cap. We have over 4 decades of experience in manufacturing of both Seamless & Welded End Cap Fittings using high quality of raw materials and manufacture by our experts team.
How we manufactured pipe fittings:
- Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
- Selection of raw material: metal; plate or pipe.
- Cutting
- Heating.
- Forming.
- Welding: for fittings that are not simple elbows, returns, bends, pipe cap or cap.
- Inspection and tests: according to standards and client requirements.
- Coating (if required).
- Preparation of documentation.
- Shipping.
ANSI/ASME B16.9 Butt weld End Cap Price List
Following is ANSI/ASME B16.9 Butt weld End Cap price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
| Materials | Price Range | Unit |
|---|---|---|
| B16.9 sch40 SS pipe fitting butt weld end cap | $10.00-$50.00 | USD/Piece |
| butt welding steel pipe end bw cap | $0.20-$1000.00 | USD/Piece |
| butt weld carbon steel end cap | $10.00-$100.00 | USD/Piece |
| Butt Welded 36″ Steel Pipe End Cap | $0.90-$500.00 | USD/Piece |
| Stainless steel end cap | $10.00-$12.00 | USD/Piece |
| Butt welded end cap | $1.00-$200.00 | USD/Piece |
| ansi b16.9 butt welded alloy steel blind end cap | $0.50-$10.00 | USD/Piece |
| 4 inch sch40 butt welded end cap | $0.50-$20.00 | USD/Piece |
| black butt weld carbon steel pipe fitting end cap | $32.00-$91.00 | USD/Piece |
| butt welded carbon steel elliptical caps | $1.00-$13.00 | USD/Piece |
| Butt Welded 30 Inch End Cap | $10.00-$100.00 | USD/Piece |
| butt welded 24″ pipe end cap | $3.80-$15.00 | USD/Piece |
| ASTM DN 150 Sch 80 CS Butt Welded End Cap | $72.00-$75.00 | USD/Piece |
| aluminium alloy butt welded end cap | $700.00-$800.00 | USD/Piece |
| Large Diameter Butt Welded End Cap | $0.50-$55.00 | USD/Piece |
| Seamless Butt Weld 2 inch SS pipe fitting cap | $0.50-$189.00 | USD/Piece |
Reference:alibaba
ASME B16.9 Butt weld End Cap Dimensions:
| CAPS – ANSI B 16.9 dimension | |||
|---|---|---|---|
| inches | mm | Height | |
| D | E | ||
| 1/2 | 15 | 21,34 | 25,40 |
| 3/4 | 20 | 26,67 | 31,75 |
| 25 | 33,40 | 38,10 | |
| 1 1/4 | 32 | 42,16 | 38,10 |
| 1 1/2 | 40 | 48,26 | 38,10 |
| 2 | 50 | 60,32 | 38,10 |
| 2 1/2 | 65 | 73,02 | 38,10 |
| 3 | 80 | 88,90 | 50,80 |
| 3 1/2 | 90 | 101,60 | 63,50 |
| 4 | 100 | 114,30 | 63,50 |
| 5 | 125 | 141,30 | 76,20 |
| 6 | 150 | 168,27 | 88,90 |
| 8 | 200 | 219,07 | 101,60 |
| 10 | 250 | 273,05 | 127,00 |
| 12 | 300 | 323,85 | 152,40 |
| 14 | 350 | 355,60 | 165,10 |
| 16 | 400 | 406,40 | 177,80 |
| 18 | 450 | 457,20 | 203,20 |
| 20 | 500 | 508,00 | 228,60 |
| 22 | 550 | 558,80 | 254,00 |
| 24 | 600 | 609,60 | 266,70 |
| 28 | 700 | 711,20 | 266,70 |
| Dimension in mm | |||
Butt weld ASME B16.9 End Cap Tolerances:
| DIMENSIONAL TOLERANCES – CAPS | ||||
|---|---|---|---|---|
| For all fittings | Caps | |||
| Nominal Pipe Size (NPS) | Outside Ø at Bevel | Inside Ø at End | Wall Thickness t / t1 |
Overall Length E |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 4 |
| 3 a 3 1/2 | 1 | 1,6 | less | 4 |
| 4 | +2 -1 | 1,6 | than | 4 |
| 5 a 6 | +3 -1 | 1,6 | 87,50% | 7 |
| 8 | 2 | 1,6 | of nominal | 7 |
| 10 | +4 -3 | 3,2 | tickness | 7 |
| 12 a 18 | +4 -3 | 3,2 | 7 | |
| 20 a 24 | +6 -5 | 4,8 | 7 | |
| 26 a 30 | +7 -5 | 4,8 | 10 | |
| 32 a 48 | +7 -5 | 4,8 | 10 | |
ANSI/ASME B16.9 Butt weld End Cap Application
Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ANSI/ASME B16.9 Butt weld End Cap and supplying to various core industries like
Chemicals Fertilizers Industries
Heat Exchanger
Instrumentation
Nuclear Thermal Industries
Oil Gas Industries
Pharmacy Surgical Industries
Refineries Petrochemicals
Water Gas Piping Systems
Cities We Export ANSI/ASME B16.9 Butt weld End Cap
|
|
|
|
Countries We Export ANSI/ASME B16.9 Butt weld End Cap
|
|
|
|
