Butt weld ASME B16.9 Reducing Cross Manufacturer

MPJain » Butt weld ASME B16.9 Reducing Cross Manufacturer

Leading ANSI/ASME B16.9 Butt weld Reducing Cross Manufacturers and Authoritative SS Reducing Cross Supplier in India and Overseas.

ANSI/ASME B16.9 Butt weld Reducing Cross Manufacturers in India

As a leading manufacturer, stockist, and exporters of butt weld reducing Cross we are providing high-quality reducing Cross pipe fitting at best price in India.

We keep the largest stock of sanitary reducing cross, reducing weld cross, stainless steel reducing Cross, carbon steel reducing Cross, nickel alloy reducing Cross, alloy steel reducing Cross, monel reducing Cross, copper reducing cross, reducing cross fitting in all dimension.

Contact Us
WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELD REDUCING CROSS / STAINLESS STEEL BUTT WELD REDUCING CROSS / DUPLEX STEEL BUTT WELD REDUCING CROSS / CARBON STEEL BUTT WELD REDUCING CROSS / ALLOY STEEL BUTT WELD REDUCING CROSS / HASTELLOY STEEL BUTT WELD REDUCING CROSS / MONEL STEEL BUTT WELD REDUCING CROSS / INCONEL STEEL BUTT WELD REDUCING CROSS / TITANIUN STEEL BUTT WELD REDUCING CROSS / SUPER DUPLEX STEEL BUTT WELD REDUCING CROSS / INCOLOY STEEL BUTT WELD REDUCING CROSS / ALLOY 20 BUTT WELD REDUCING CROSS / 254 SMO BUTT WELD REDUCING CROSS/ COPPER NICKEL STEEL BUTT WELD REDUCING CROSS
ANSI/ASME B16.9 Butt weld Reducing Cross Exporter in India

ANSI/ASME B16.9 Butt weld Reducing Cross Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic   Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Long Radius Elbows and   Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low   Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS   B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80,   S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt weld Reducing Cross Materials and Grade

Stainless Steel Butt weld Reducing Cross:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Reducing Cross:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Reducing Cross:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Reducing Cross:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt weld Reducing Cross in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Butt weld Reducing Cross. We keep intensive stock of Reducing Cross Pipe Fitting to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI Reducing Cross. We have over 4 decades of experience in manufacturing of both Seamless & Welded Pipe Reducing Cross Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, reducers or caps.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt weld Reducing Cross Price List

Following is ANSI/ASME B16.9 Butt weld Reducing Cross price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Butt Welding Reducing Cross $1.00-$10.00 USD/Piece
ANSI butt weld fittings reducing cross $3.00-$38.00 USD/Piece
CS butt welded reducing cross $1.00-$100.00 USD/Piece
Stainless steel seamless butt weld Reducing Crosses $8.00-$1000.00 USD/Piece
ASME B16.9 carbon steel weld reducing SCH 40 cross $1.00-$99.00 USD/Piece
Carbon Steel Seamless Reducing Cross $10.00-$1000.00 USD/Piece
reducing outlet crosses for industrial $5.00-$99.00 USD/Piece
Welding Straight Cross $132.00 USD/Piece
butt weld pipe cross 1-4″ $1.00-$50.00 USD/Piece
SS pipe fittings 4 port butt welding Cross $0.56-$22.00 USD/Piece
sanitary SS pipe fitting butt weld 4 way cross connector $1.00-$25.00 USD/Piece
8 inch carbon steel butt weld pipe cross $0.25-$60.00 USD/Piece

Reference:alibaba

ASME B16.9 Butt weld Reducing Cross Dimensions:

Nominal Diameter Outside Diameter Center to End
D1 D2
DN NPS Series A Series B Series A Series B C M
15×15 1/2×1/2 21.3 18 21.3 18 25 25
15×10 1/2×3/8 21.3 18 17.3 14 25 25
15×8 1/2×1/4 21.3 18 13.7 10 25 25
20×20 3/4×3/4 26.9 25 26.9 25 29 29
20×15 3/4×1/2 26.9 25 21.3 18 29 29
20×10 3/4×3/8 26.9 25 17.3 14 29 29
25×25 1×1 33.7 32 33.7 32 38 38
25×20 1×3/4 33.7 32 26.9 25 38 38
25×15 1×1/2 33.7 32 21.3 18 38 38
32×32 1.1/4×1.1/4 42.4 38 42.4 38 48 48
32×25 1.1/4×1 42.4 38 33.7 32 48 48
32×20 1.1/4×3/4 42.4 38 26.9 25 48 48
32×15 1.1/4×1/2 42.4 38 21.3 18 48 48
40×40 1.1/2×1.1/2 48.3 45 48.3 45 57 57
40×32 1.1/2×1.1/4 48.3 45 42.4 38 57 57
40×25 1.1/2×1 48.3 45 33.7 32 57 57
40×20 1.1/2×3/4 48.3 45 26.9 25 57 57
40×15 1.1/2×1/2 48.3 45 21.3 18 57 57
50×50 2×2 60.3 57 60.3 57 64 64
50×40 2×1.1/2 60.3 57 48.3 45 64 60
50×32 2×1.1/4 60.3 57 42.4 38 64 57
50×25 2×1 60.3 57 33.7 32 64 51
50×20 2×3/4 60.3 57 26.9 25 64 44
65×65 2/1/2×2.1/2 73.0 76 73.0 76 76 76
65×50 2/1/2×2 73.0 76 60.3 57 76 70
65×40 2/1/2×1.1/2 73.0 76 48.3 45 76 67
65×32 2/1/2×1.1/4 73.0 76 42.4 38 76 64
65×25 2/1/2×1 73.0 76 33.7 32 76 57
80×80 3×3 88.9 89 88.9 89 86 86
80×65 3×2.1/2 88.9 89 73.0 76 86 83
80×50 3×2 88.9 89 60.3 57 86 76
80×40 3×1.1/2 88.9 89 48.3 45 86 73
80×32 3×1.1/4 88.9 89 42.4 38 86 70
90×90 3.1/2×3.1/2 101.6 – 101.6 – 95 95
90×80 3.1/2×3 101.6 – 88.9 89 95 92
90×65 3.1/2×2.1/2 101.6 – 73.0 76 95 89
90×50 3.1/2×2 101.6 – 60.3 57 95 83
90×40 3.1/2×1.1/2 101.6 – 48.3 45 95 79
100×100 4×4 114.3 108 114.3 108 105 105
100×90 4×3.1/2 114.3 108 101.6 – 105 102
100×80 4×3 114.3 108 88.9 89 105 98
100×65 4×2.1/2 114.3 108 73.0 76 105 95
100×50 4×2 114.3 108 60.3 57 105 89
100×40 4×1.1/2 114.3 108 48.3 45 105 86
125×125 5×5 141.3 133 141.3 133 124 124
125×100 5×4 141.3 133 114.3 108 124 117
125×90 5×3.1/2 141.3 – 101.6 – 124 114
125×80 5×3 141.3 133 88.9 89 124 111
125×65 5×2.1.2 141.3 133 73.0 76 124 108
125×50 5×2 141.3 133 60.3 57 124 105
150×150 6×6 168.3 159 168.3 159 143 143
150×125 6×5 168.3 159 141.3 133 143 137
150×100 6×4 168.3 159 114.3 108 143 130
150×90 6×3.1/2 168.3 – 101.6 – 143 127
150×80 6×3 168.3 159 88.9 89 143 124
150×65 6×2.1/2 168.3 159 73.0 76 143 121
200×200 8×8 219.1 219 219.1 219 178 178
200×150 8×6 219.1 219 168.3 159 178 168
200×125 8×5 219.1 219 141.4 133 178 162
200×100 8×4 219.1 219 114.3 108 178 156
200×90 8×3.1/2 219.1 – 101.6 – 178 152
250×250 10×10 273.0 273 273.0 273 216 216
250×200 10×8 273.0 273 219.1 219 216 203
250×150 10×6 273.0 273 168.3 159 216 194
250×125 10×5 273.0 273 141.3 133 216 191
250×100 10×4 273.0 273 114.3 108 216 184
300×300 12×12 323.9 325 323.9 325 254 254
300×250 12×10 323.9 325 273.0 273 254 241
300×200 12×8 323.9 325 219.1 219 254 229
300×150 12×6 323.9 325 168.3 159 254 219
300×125 12×5 323.9 325 141.3 133 254 216
350×350 14×14 355.6 377 355.6 377 279 279
350×300 14×12 355.6 377 323.9 325 279 270
350×250 14×10 355.6 377 273.0 273 279 257
350×200 14×8 355.6 377 219.1 219 279 248
350×150 14×6 355.6 377 168.3 159 279 238
400×400 16×16 406.4 426 406.4 426 305 305
400×350 16×14 406.4 426 355.6 377 305 305
400×300 16×12 406.4 426 323.9 325 305 295
400×250 16×10 406.4 426 273.0 273 305 283
400×200 16×8 406.4 426 219.1 219 305 273
400×150 16×6 406.4 426 168.3 159 305 264
450×450 18×18 457 480 457 480 343 343
450×400 18×16 457 480 406.4 426 343 330
450×350 18×14 457 480 355.6 377 343 330
450×300 18×12 457 480 323.9 325 343 321
450×250 18×10 457 480 273.0 273 343 308
450×200 18×8 457 480 219.1 219 343 298
500×500 20×20 508 530 508 530 381 381
500×450 20×20 508 530 457 480 381 368
500×400 20×20 508 530 406.4 426 381 356
500×350 20×20 508 530 355.6 377 381 356
500×300 20×20 508 530 323.9 325 381 346
500×250 20×20 508 530 273.0 273 381 333
500×200 20×20 508 530 219.1 219 381 324

ANSI/ASME B16.9 Butt weld Reducing Cross Application

Today M P Jain Tubing Solutions LLP is one of the leading manufacturer, stockists, and exporters of ASME B16.9 Butt weld Reducing Cross and supplying to various core industries like
Chemicals Fertilizers Industries
Chemicals Fertilizers Industries
Heat Exchanger
Heat Exchanger
Instrumentation
Instrumentation
Nuclear Thermal Industries
Nuclear Thermal Industries
Oil Gas Industries
Oil Gas Industries
Pharmacy Surgical Industries
Pharmacy Surgical Industries
Refineries Petrochemicals
Refineries Petrochemicals
Water Gas Piping Systems
Water Gas Piping Systems
