Buttweld ASME B16.9 Reducing Nipple Manufacturer

MPJain » Buttweld ASME B16.9 Reducing Nipple Manufacturer

Leading ANSI/ASME B16.9 Butt welding Reducing Nipple Manufacturers and Authoritative SS Reducing Nipple Supplier in India and Overseas.

ANSI/ASME B16.9 Butt welding Reducing Nipple Manufacturers in India

As a leading manufacturer, stockist, and exporters of ANSI/ASME B16.9 butt welding reducing nipple, we are providing high-quality Reducing Nipple Pipe Fitting at best price in India.

We keep the largest stock of stainless steel reducing nipple, carbon steel reducing nipple, nickel alloy reducing nipple, alloy steel reducing nipple, monel reducing nipple in all dimensions.

Contact Us
WE ARE MANUFACTURING ANSI/ASME B16.9 BUTT WELDING REDUCING NIPPLE / STAINLESS STEEL BUTT WELD REDUCING NIPPLE / DUPLEX STEEL BUTT WELD REDUCING NIPPLE / CARBON STEEL BUTT WELD REDUCING NIPPLE / ALLOY STEEL BUTT WELD REDUCING NIPPLE / HASTELLOY STEEL BUTT WELD REDUCING NIPPLE / MONEL STEEL BUTT WELD REDUCING NIPPLE / INCONEL STEEL BUTT WELD REDUCING NIPPLE / TITANIUN STEEL BUTT WELD REDUCING NIPPLE / SUPER DUPLEX STEEL BUTT WELD REDUCING NIPPLE / INCOLOY STEEL BUTT WELD REDUCING NIPPLE / ALLOY 20 BUTT WELD REDUCING NIPPLE / 254 SMO BUTT WELD REDUCING NIPPLE/ COPPER NICKEL STEEL BUTT WELD REDUCING NIPPLE
ANSI/ASME B16.9 Butt welding Reducing Nipple Exporter in India

ANSI/ASME B16.9 Butt welding Reducing Nipple Specifications

Type Butt weld (BW)
Standards ASME / ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless steel Piping Fittings’
API 590-605
ASME B16.9 – ‘Factory-Made Wrought Buttwelding Fittings’
ASME B16.25 – ‘Buttwelding Ends’
ASME B16.28 – ‘Wrought steel Buttwelding Short Radius Elbows and Returns’
MSS SP-43 – ‘Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications’
Dimension ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule Sch 5 TO Sch XXS.
Size 1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

ANSI/ASME B16.9 Butt welding Reducing Nipple Materials and Grade

Stainless Steel Butt weld Reducing Nipple:

  • ASTM A403 WP316/316L
  • ASTM A403 WP304/304L
  • ASTM A182 F316L, 304L
  • DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Butt weld Reducing Nipple:

  • ASTM A234 Gr. WPB
  • ASTM A420 Gr. WPL6
  • ASTM A105
  • ASTM A350 Gr. LF2

Nickel Alloy Butt weld Reducing Nipple:

  • Monel 400 & 500
  • Inconel 600 & 625
  • Incolloy 800, 825
  • Hastelloy C22, C276
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Alloy20
  • Copper Nickel
  • Cupro-Nickel 90/10
  • Cupro-Nickel 70/30

Alloy Steel Butt weld Reducing Nipple:

  • ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

Why Choose M P Jain Tubing Solutions LLP

M P Jain Tubing Solutions LLP is one of the leading Manufacturer, Stockist, and Exporter of ANSI/ASME B16.9 Butt welding Reducing Nipple in Mumbai, India. We are in this domain since 1972. We are ISO 9001:2015 certified company and most trusted Suppliers of SS Buttweld Reducing Nipple. We keep intensive stock of Reducing Nipple Pipe Fittings to fulfil urgent requirements of our clients at reasonable prices.

We are committed to on-time delivery of ANSI B16.9 Reducing Nipple. We have over 4 decades of experience in manufacturing of both Seamless & Welded Reducing Nipple Fittings using high quality of raw materials and manufacture by our experts team.

How we manufactured pipe fittings:

  • Planning: based on fitting specifics and client requirements; includes creating part identification in a manufacturing system.
  • Selection of raw material: metal; plate or pipe.
  • Cutting
  • Heating.
  • Forming.
  • Welding: for fittings that are not simple elbows, returns, bends, pipe cap or cap.
  • Inspection and tests: according to standards and client requirements.
  • Coating (if required).
  • Preparation of documentation.
  • Shipping.

ANSI/ASME B16.9 Butt welding Reducing Nipple Price List

Following is ANSI/ASME B16.9 Butt welding Reducing Nipple price in India. This price range also depends on minimum order and might vary without any prior information. For more details contact us now and get Instant Quote.
Materials Price Range Unit
Stainless Steel Reducing Nipple $1.00-$50.00 USD/Piece
1-1/2″Male Thread Reducing Nipple $0.01-$5.00 USD/Piece
stainless steel reducing hex nipple $1.00-$10.00 USD/Piece
Reducing Long Length Brass Pipe Nipple $0.20-$20.00 USD/Piece
Brass barb hose male reducing hex nipple $1.00-$99.00 USD/Piece
Reduced Nipple Male Nipple $0.10-$3.00 USD/Piece
reducing galvanized carbon steel pipe nipple $0.10-$8.00 USD/Piece
Thread reducing hexagon nipple for water,gas $1.00-$2.00 USD/Piece
SS 1/4″ to 1/8″ NPT Reducing Thread Hex Nipple $4.00-$10.00 USD/Piece
copper hex threaded reducing nipple $0.26-$0.45 USD/Piece

Reference:alibaba

ANSI/ASME B16.9 Butt welding Reducing Nipple Dimensions:

Standard Pattern
SIZE A B L W
mm in mm in mm in mm in
1/4" 1/8" 13  0.51  6 0.24 31  1.22  15.1 0.59
3/8" 1/8" 14  0.55  7 0.28 34  1.34  18.6 0.73
1/4" 14  0.55  7 0.28 34  1.34  18.6 0.73
1/2" 1/8" 16.5  0.65  8  0.31  36.5  1.44  23 0.91
1/4" 16.5  0.65  8  0.31  36.5  1.44  23 0.91
3/8" 16.5  0.65  8  0.31  36.5  1.44  23 0.91
3/4" 1/8" 16  0.63  8  0.31  40  1.57  29  1.14
1/4" 16  0.63  8  0.31  40  1.57  29  1.14
3/8" 17  0.67  8  0.31  41  1.61  28.5  1.12
1/2" 17  0.67  8  0.31  41.5  1.63  28.5  1.12
1" 1/4" 20  0.79  9 0.35 41  1.61  35.4  1.39
3/8" 20  0.79  9 0.35 42.5  1.67  35.4  1.39
1/2" 20  0.79  9 0.35 45  1.77  35.4  1.39
3/4" 20  0.79  9 0.35 45  1.77  35.4  1.39
1-1/4" 1/4" 21  0.83  10 0.39 42  1.65  44.5  1.75
3/8" 21  0.83  10 0.39 47  1.85  44.5  1.75
1/2" 21  0.83  10 0.39 49  1.93  44.5  1.75
3/4" 21  0.83  10 0.39 49  1.93  44.5  1.75
1" 22  0.87  10 0.39 52  2.05  44.5  1.75
1-1/2" 1/4" 20  0.79  10.5 0.41 42.5  1.65  51  2.01
3/8" 21  0.83  10  0.39  47  1.85  50  1.97
1/2" 21  0.83  10  0.39  49  1.93  50  1.97
3/4" 21  0.83  10  0.39  49  1.93  50  1.97
1" 21.5  0.85 11  0.39  52.5  2.07  50  1.97
1-1/4" 22  0.87  11  0.43  55  2.17  51  2.01
2" 3/8" 23  0.91  11 0.43 52  2.05  61.5  2.42
1/2" 23  0.91  11 0.43 52  2.05  61.5  2.42
3/4" 23  0.91  11 0.43 41.5  1.63  61.5  2.42
1" 23  0.91  11 0.43 53.5  2.11  61.5  2.42
1-1/4" 23  0.91  11 0.43 56  2.2  61.5  2.42
1-1/2" 23  0.91  11 0.43 55.5  2.19  61.5  2.42
2-1/2" 3/4" 27.5  1.08  13 0.51 64  2.52  78  3.07
1" 27.5  1.08  13 0.51 63.5  2.5  78  3.07
1-1/4" 27.5  1.08  13 0.51 63.5  2.5  78  3.07
1-1/2" 27.5  1.08  13 0.51 63.5  2.5  78  3.07
2" 27.5  1.08  13 0.51 65.5  2.58  78  3.07
3" 1-1/2" 28  1.1  15 0.59 68  2.68  92  3.62
2" 28  1.1  15 0.59 68.5  2.7  93  3.66
2-1/2" 28.5  1.12  15 0.59 71  2.8  92  3.62
4" 2" 30  1.18  15 0.59 75  2.95  117  4.61
2-1/2" 30  1.18  15 0.59 75  2.95  117  4.61
3" 30  1.18  15 0.59 75  2.95  117  4.61

Tolerance: +0.5mm(1/8"~2")
+0.8mm(2-1/2"~4")

Economic Pattern
SIZE A B L W
mm in mm in mm in mm in
1/4" 1/8" 11 0.43 6 0.24 29 1.14 15 0.59
3/8" 1/8" 12 0.47 7 0.28 31 1.22 18 0.71
1/4" 12 0.47 7 0.28 32 1.26 18 0.71
1/2" 1/8" 14 0.55 7 0.28 34 1.34 23 0.91
1/4" 14 0.55 7 0.28 35 1.38 23 0.91
3/8" 14 0.55 7 0.28 36 1.42 23 0.91
3/4" 1/8" 14 0.55 7 0.28 34 1.34 29 1.14
1/4" 14 0.55 7 0.28 35 1.38 29 1.14
3/8" 14 0.55 7 0.28 36 1.42 29 1.14
1/2" 14 0.55 7 0.28 39 1.54 29 1.14
1" 1/4" 17.5 0.69 9 0.35 41 1.61 35 1.38
3/8" 17.5 0.69 9 0.35 42 1.65 35 1.38
1/2" 17.5 0.69 9 0.35 45 1.77 35 1.38
3/4" 17.5 0.69 9 0.35 45 1.77 35 1.38
1-1/4" 1/4" 18 0.71 10 0.39 42 1.65 45 1.77
3/8" 18 0.71 10 0.39 43 1.69 45 1.77
1/2" 18 0.71 10 0.39 46 1.81 45 1.77
3/4" 18 0.71 10 0.39 46 1.81 45 1.77
1" 18 0.71 10 0.39 50 1.97 45 1.77
1-1/2" 1/4" 18.5 0.73 10.5 0.41 42.5 1.67 50 1.97
3/8" 18.5 0.73 10.5 0.41 43.5 1.71 50 1.97
1/2" 18.5 0.73 10.5 0.41 46.5 1.83 50 1.97
3/4" 18.5 0.73 10.5 0.41 46.5 1.83 50 1.97
1" 18.5 0.73 10.5 0.41 50.5 1.99 50 1.97
1-1/4" 18.5 0.73 10.5 0.41 50.5 1.99 50 1.97
2" 3/8" 20 0.79 11 0.43 45 1.77 62 2.44
1/2" 20 0.79 11 0.43 48 1.89 62 2.44
3/4" 20 0.79 11 0.43 48 1.89 62 2.44
1" 20 0.79 11 0.43 52 2.05 62 2.44
1-1/4" 20 0.79 11 0.43 52 2.05 62 2.44
1-1/2" 20 0.79 11 0.43 52 2.05 62 2.44
2-1/2" 3/4" 22.5 0.89 13 0.51 52.5 2.07 78 3.07
1" 22.5 0.89 13 0.51 56.5 2.22 78 3.07
1-1/4" 22.5 0.89 13 0.51 56.5 2.22 78 3.07
1-1/2" 22.5 0.89 13 0.51 56.5 2.22 78 3.07
2" 22.5 0.89 13 0.51 57.5 2.26 78 3.07
3" 1-1/2" 25 0.98 15 0.59 61 2.4 91 3.58
2" 25 0.98 15 0.59 62 2.44 91 3.58
2-1/2" 25 0.98 15 0.59 64.5 2.54 91 3.58
4" 2" 27 1.06 15 0.59 64 2.52 117 4.61
2-1/2" 27 1.06 15 0.59 66.5 2.62 117 4.61
3" 27 1.06 15 0.59 69 2.72 117 4.61

Tolerance: +0.5mm(1/8"~2")
+0.8mm(2-1/2"~4")
